Oil Gilding the Council of Archangel Michael (pt2)

Summer is the best time for gessoing icon boards. It’s a messy job and I like to make the most of working outside especially sanding the boards. I wrote about the method of gessoing on an earlier post here.

3 sanding the large icon board.jpg

Making the most of a dry sunny day to sand the gesso smooth

I felt that the icon of the Council of the Archangel Michael should be painted on a large board as there are a lot of figures. I don’t know the size of the original icon, but small faces can be tricky so the size I went for was the optimum I can work with at home: 40 x 42cm. With it being cut from 24mm birch ply it’s quite heavy.

I placed the board on a towel to prevent it from sliding around the table whilst I sand. Red ochre rubbed over the surface helps to show up any scratches I had missed.

Once it had been sanded down with 1200 grade sandpaper, it was ready to oil gild. I chose the oil gilding method (matt finish gold) because it’s more robust than water gilding.  Having so many figures and faces it will be handled quite a bit during painting.

finding scratches

Red ochre shows up scratches which still need to be sanded

I moved my drawings on to tracing paper so it was ready to transcribe on to the gesso. Although it is possible to oil gild after painting, I prefer to gild before painting the faces. I find both methods of gilding challenging so I will keep practising!

It isn’t necessary to scribe the areas to be gilded with the oil gilding method but I find it helps contain the shellac. Aidan Hart protects the gesso from the compass points with a wooden ruler which works very well but if you don’t have a ruler to hand, several layers of masking tape over some card helps (see photos below).

transcribing halo on icon

compass points on gesso

Protecting the gesso from compass puncture marks

Anyone of a ‘certain age’ will understand when I say that some red ochre rubbed over the scribed areas helps me to see where I’m going!

transcribing drawing

Aidan taught us the following method of oil gilding which I will summarise below. You can also see some amatuer video clips from our class demonstration on You Tube here.

Gold transfer leaf is applied on to several layers of shellac but first the gesso is sealed by painting on a thin layer of tinted shellac. Tinting is done with a pinch of red ochre or vermillion. Leave it to dry for a day then lightly sand working your way through the sandpaper grades from 600-1200. The following day, repeat the process but using untinted shellac. Leave it for a day and then sand as before.

shellac on halos for icon gilding

Shellac ready to sand

It is then ready to gild. Aidan suggested using Le Franc’s 3 hour gold size. Shake well then apply one very thin layer and place it in a dust free place, like a plastic box.

Wait for an hour at least (1-3 hours) then test whether it is ready to gild by touching the surface with your knuckle. If it squeaks, it is ready to apply gold transfer leaf. If not, wait a little longer and re-test. Drying time depends on the thickness of the layer and the drying conditions.

Small areas of shellac are fiddly to sand smooth and as you can see under the scrutiny of the camera, there are a few missing dots. However, I’ve since touched these up with some shell gold.

oil gilding on icon

Oil gilded halos

Wait two or three hours and then it should be ready to polish the gold using a gilder’s mop, working from light to medium pressure.

After waiting a few days to let the gilding harden, I could carry on with transferring the rest of my drawing.

transfer of whole drawing

Gilding complete, time to transcribe the rest of the drawing

I kept the compass protection pads on so I could add the halo outlines as soon as the sky had been painted. That’s all for this post but I will sign off with a photo of the icon a bit further along.

underpainting icon of Council of Archangel Michael

Outlines of figures applied and underpainting begins

Once again, thanks for reading!

Ronnie

Archangels in Blossom Street (Pt1)

Icon of Archangel gabriel resting on pic of Blossom Street

Archangel Gabriel in Blossom Street York

Kim and Jules run the Blossom Street Gallery, just outside Micklegate Bar in York. They stock my Drawing the Street limited edition prints and in February this year, I called in to catch up with them having finished the icon diploma.

I had a tiny icon of Archangel Gabriel with me which I brought out to show them as I was telling them about the course. One thing led to another and I am now booked in for a joint exhibition of icons and streets next Spring!

I had a few ideas for themes for the icon exhibition, but none were really firing me up, so I sent a request up to the heavens and within the day I had my theme and central icon. I subscribe to a blog by ‘Hokku’ and this timely post landed in my inbox:https://russianicons.wordpress.com/2017/03/20/the-council-of-the-archangel-michael/

Blossom Street Gallery is almost opposite my former school, All Saints, previously called The Bar Convent when I attended. There was a school legend that the Archangel Michael had once appeared there to protect the convent from imminent danger. So, when I saw this icon called ‘the Council of the Archangel Michael, I knew I had found my centre piece icon and my theme ‘A Gathering of Angels’.

A year isn’t long to prepare for an icon exhibition so I got started with the drawings.  It was a wonderful way to focus during what turned out to be a bumpy few months.



I made an unplanned visit to my sister in Perth WA who was unwell but I find sketching and drawing icon figures very calming.  I wrote a little about the visit over here.

The Council of Archangel Michael is a rich icon and full of life so I drew the main figures separately in turn. I drew the cherubim below late into the evening while my sister rested. I smile and am so grateful for all the help we are still recieving from these celestial helpers.

pencil drawing of cherubim

Cherubim from the Council of Archangel Michael icon

pencil drawing of young christ and seraphim

Drawing of the young Christ within a circle of seraphim

pencil drawing of Council of Angels

Full drawing ready to transcribe

The overall drawing is too big for me to scan at home but the photo gives you an idea of the overall composition. The finished icon will be just over 40cm square.

Hope you will join me as the rest of this icon unfolds!

Thanks for reading – more to follow soon.

Ronnie

St David the Dendrite (part 3 of 3)

Here’s the icon of St David taking shape. It is painted on a long thin board, 25mm birch ply. This post is mostly photos but always happy to hear from you if you have any questions.

icon painting studio

St David the Dendrite (tree dweller) of Thessaloniki

St David the dendrite of thessaloniki icon

Lines transcribed in red ochre on to gessoed board (photo enhanced for clarity)

The masking tape is to protect the gesso from the compass point.

terre verte pigment on icon

First washes of terre verte over background

adding a wash of lapis lazuli over the terre verte

Adding a wash of lapis lazuli over the terre verte

green background on icon of st david

Finishing background so I can add outline to halo

underpainting the face

underpainting the face

jaipur paint brush in use

David and Crystal visited India and brought me back a brush from Jaipur

completed icon (in part) of St David with his open hand feeding a robin

completed icon (in part) of St David with his open hand feeding a robin

7 membrane over face

Membrane applied in thin layers to face using yellow maimeri and a dash of english red ochre light.

Thanks for reading!

Ronnie

Cornelia and Hironmoy remembered

paionting of lord krishna on watercolour paper

Lord Krishna

My great aunt, Cornelia Maria Georgina Sharp, was born on 8th December 1891, the second child in a family of six. It was years later that we discovered a little more of this courageous woman’s life when Dad’s cousin researched into what had happened to his absent father.

I am touching on her story here as I was delighted to be commissioned to paint an icon of Lord Krishna, the god of compassion, tenderness and love in Hinduism and happy that we have a family connection to this rich faith.

lord krishna outline drawing

Transcribing the lines of outline drawing onto paper

In brief, Cornelia, a young English Catholic woman working in service, married a young Indian Hindu man named Hironmoy Roy-Chowdury in the Church of the Holy Rood, Watford. All the more extraordinary was that her new husband was the nephew of poet and winner of the Nobel Prize for literature  Rabindranath Tagore

Hironmoy was a sculptor studying at the Royal College of Art. Their only child, Francis Roy Chowdury (Dad’s cousin), was born in October 1914 two months after the outbreak of the first world war. The marriage wasn’t to last long as Hironmoy went to France to volunteer in an abulance unit and then his family heard of the marriage and insisted he return to India.

2 line on paper

First lines on paper

Back to the icon of Lord Krishna where I’ve depicted him as a young man playing the flute, standing on a lotus flower. He is painted on 600gsm hot pressed paper mounted on a 25mm ply board rather than on gesso thereby avoiding the use of rabbit skin size.

gold leaf on lord krishna drawing

Applying 24 carat transfer gold leaf over acrylic size coloured with a little red ochre

lord krishna on heavenly gold background

Lord Krishna standing against the gold of heaven

5 underpainting

Underpainting the figure and garments

egg tempera

Applying the paint in thin layers

lapis lazuli

Flesh tones painted in Lapis Lazuli

The colours on images of Lord Krishna are vibrant but to avoid them clashing, I limited the palette to English red ochre, yellow ochre maimeri, lapis lazuli, black and white. The greens were mixed from malachite.

I chose to use Lapis Lazuli as its deep, celestial blue remains the symbol of royalty and honor, gods and power, spirit and vision, wisdom and truth. Its name comes from the Latin lapis, “stone,” and the Persian lazhuward, “blue.”

qualities of Lord krishna

Some of the many qualities with which Lord Krishna is associated

Lord Krishna painted using the icon method

Lord Krishna ready for his new home

There must be enough for a book on the subject of Cornelia and Hironmoy’s brief lives together and it is a treasure that we know of this through their son’s research.

I will close with a quote from ‘Fruit Gathering’ by Rabindranath Tagore;

        ‘Send me the love which is cool and pure like your rain that blesses the thirsty earth       and fills the homely earthen jars.

         Send me the love that would soak down into the centre of being, and from there would spread like the unseen sap through the branching tree of life, giving birth to fruits and flowers.’

Thanks for reading,

Ronnie

Membrane Technique for icon faces

icon painter's work space

Spring cleaned workspace

I’ve had a few requests for a glimpse at my notes from the icon diploma course taught by Aidan Hart at the PSTA. There are a lot to sift through and they’re a bit illegible, even to me. However, I plan to revisit and re-write them at each stage of painting an icon but bear with me as this may take a while!

painting with italian Gold Ochre pigment and Ivory black

Underpainting the faces

I’ve already made a start with the pigment grinding crib sheet and now that I’m currently underpainting an icon, I’ve written up my notes for this stage. They are on my website on the Crib Sheet page and I will share a link at the end of this post.

underpainting face of Blessed Virgin and Christ Child

Underpainting complete

For the underpainting, I’ve found that mixing an earth green from Italian yellow ochre and ivory black has been a little less sticky than using terre verte.

Don’t forget to apply a dilute wash over all the unpainted areas before applying the membrane or it won’t cover evenly.

I still find it tricky to apply the membrane layers evenly but at least I know better not to fiddle with uneven areas. Just go and do something else for a few hours to let it properly dry then apply another couple of thin layers.

icon painting with membrane technique

Three layers of thinly painted membrane applied

Next stage is applying the shading and highlights, but for now here are my notes: Membrane technique part one underpainting and membrane

By the way, the pigment grinding demonstration went well. More on the results of that when I use the pigment to paint!

finished mid tones on an icon face

Five layers of the membrane applied

Thanks for reading,

Ronnie

Crib Sheet No 1: Grinding Azurite to make Pigment for Paint

azurite-from-burslem-lapidary

Azurite in its mineral form

I recently volunteered to give a demonstration of grinding minerals to make pigment for painting to a local networking group – W.I.R.E. (Women in Rural Enterprises). I haven’t given a demonstration before but since it will be a small friendly audience, it’s a good place for me to make a start.

slab and muller with azurite

Slab and muller to grind up the pigment

I’ve written several times already about grinding pigments but this time I’ve gathered my notes together as a crib sheet which you can downdoad grinding-azurite-for-painting-by-ronnie-cruwysas a four page pdf.

I’ve also just set up a fixed page on this website, called ‘Crib Sheets’, which I hope to add to in future. This first set of notes has been saved to the new page and I hope to add many more…well, that’s the plan!

Thanks for reading.

Ronnie

Herald of Spring

Greetings icon friends!

Warmest wishes for Candlemas on Thursday!  Here’s Archangel Gabriel, first icon of 2017.

icon by Cruwys

Archangel Gabriel

This post is short and sweet while I’m gathering my thoughts on varnishing icons…or rather questions. I’d love to hear of people’s preferences – there seem to be so many options yet each with drawbacks.

Bye for now

Ronnie

PS Prints and cards of this icon are now available from Smith York Printers.

All gone quiet

It’s all hands on deck at home as finishing off seems to take almost as long as actually painting an icon. Our last icon session is only days away and details of the graduation show next month are now up on the PSTA website. I would be delighted if you could come along though I know many of you are miles away. It promises to be a great show as my fellow students have produced some breath-taking work.

I plan to continue with the blog after the course has finished as I haven’t posted any where near as much as I had intended.

I will be back in touch when I get a moment and will leave you with these two icons which are almost complete…varnishing, picture hooks and cord still to add.

iconpainting of St Hilda of Whitby by Ronnie Cruwys

St Hilda of Whitby

Icon painting in egg tempera of St Francis of Assisi

St Francis of Assis

Thanks for reading!

Ronnie







Face lifts and highlights

banner mandilion

It’s now feeling uncomfortably close to the end of this course – and I haven’t finished one of my set icon pieces!  So, for the last few days I have knuckled down and revisited my first project, the Mandilion. It’s been untouched now for two years and looking back I’ve learned a bit but there is much more still to practice.

Before we go on, if you’d like to see the earlier stages of this mandilion project, you can look back here and a bit later here.

I deliberately stopped working on the mandilion as I wanted to get a bit more experience under my belt before I finished it. I’m glad I did as looking at it afresh, I could see quite a few things that need attention.

Before I set to work, I had a good look again at the prototype that I’m working from:

icon of Sinai Christ Pantocrator

Christ from the Grand Deeisis, St Catherine’s monastery, Sinai

mandilion  before editing.jpg

My version of the mandilion from two years ago.

Here’s the list of the main things to work on:

  1. Halo too bright. Vibrant lapis lazuli competes too much with the face.
  2. Left side is the ‘nearer’ side yet the righ eye is much bigger. Rebalance eyes and brow.
  3. Hair is a bit dull and lifeless.
  4. Facial tones lacks warmth.
  5. Strengthen eyebrows and shadows.
1 Rub out halo on mandilion.jpg

Scrubbing off the bright blue

Since it’s such a long time since I’ve worked on the icon, I started by applying a couple  of glaze coats over the entire face and hair to provide a key between old and new. When these had dried I then applied two thin glazes of French Ochre Havanna over the face (but not hair/eyes). Whilst it was drying, I made a start removing the bright blue halo and the unsightly black lines – what was I thinking?! I still wanted a blue halo but not as vivid, so I used a flat headed brush to soak the paint and scrub most of it off. The black lines had set quite hard though and I ended up carefully scraping them off with the tip of a blade.

3 halo and hair mandilion.jpg

Underpainting the halo and adding shading to the hair parting

I had seen a graded blue halo on a contemporary mandilion which I thought would work, and began by underpainting the bands of blue using lapis lazuli dark, titanium white and a touch of ivory black .

4 fine coat of white.jpg

When the paint is dry, I applied a weak egg glaze, then added a fine mist coat of white.

At first, the fine coat of white seems to cloak the colour too much but if it is applied as a thin layer, it soon dries much lighter and transulcent. It took three or four mist coats before the blues blended and softened.

While the paint was drying, I made a start on modelling the hair. I applied ivory black in thin layers to the parting and to the sides of the head to strengthen the form, paying attention to the ‘waves’ and the ‘ripples’.

5 modelling hair 2.jpg

To add a little warmth to the hair, I added a thin layer of English Red Ochre either side of some of the ripples towards the front.

Now for the eye surgery. The eye on the right was much too big, especially as it is on the receding side. I applied a thin layer of white over the upper eye lid and it looked green! I reduced the right hand side of the iris and lowered the shadow between lid and brow. When all dry, I then applied French ochre havanah over the eye flesh to help harmonise the colours.

eye op 1.jpg

Eye surgery – lowering the upper lid and lifting the lower lid

Then, on the pic below, you can see where I added the new line of the upper eye lid. I may revisit this eye, but it’s step in the right direction.





red and green

Red shadow under hair on near side to help it advance, green to the right

Warm colours advance and cool colours recede and you can often find faces with a wash of red somewhere on the near side and cool green on the far side.  On this icon, the left side of the face is the nearest, so I used a thin wash of red ochre under the hair line to add a warm shadow and a light green (cool)  on the right to help this side recede.

eye surgery 2

I added a little more cinnabar to the lips, corners of eyes, nose and ears (after this photo was taken) and will let it settle overnight.

Thanks for reading.

Ronnie

PS Prints and cards are now available to order from Smith York Printers.







Armenian Nativity on Vellum

1 banner armenian nativity Cruwys

Armenian Nativity on Vellum

Every now and then, I come across a manuscript or icon that captivates me. This is one of those pieces. The original can be seen here attributed to Toros Roslin, the 13th century Armenian illuminator.

Although I’m currently working on a large nativity icon for the diploma (which we have to compose ourselves rather than copy)  I side-tracked to paint this particular nativity scene on vellum as Aidan has encouraged us to study other icons to really get into the essence of the feast we have chosen.

Some 12 years ago, I went to Patricia Lovett’s Traditional Skills and Gilding course, which she ran over four days. I learnt how to stretch vellum and to prepare it for painting and gilding and she ignited an enthusiasm for this art which helped direct me towards embarking on the icon diploma. I had a piece of goatskin vellum from William Cowley already stretched on to a plywood board ready for painting so I set straight to work transferring the cartoon on to the vellum in the same way as I would for an icon, by rubbing red pigment in to the back of the cartoon paper, then setting the pigment with a watery red ochre line.

Red drawing outlines on to vellum

Transfer the cartoon on to the vellum

Next step was to lay the gesso for gilding. When we were on Patricia’s gilding course, she advised us to make detailed notes on the method. For anyone who would like to learn more, my notes from one of the gilding days are here and I would also recommend Patricia’s books and dvd’s on gilding available through her website. The ‘Gilding gesso on vellum’ notes can be downloaded as a pdf here.

First washes of Caput Mortum on vellum

Caput mortum used for the earth and shepherd figure

gesso on vellum

Laying gesso for halos, irregularities to be scraped and burnished then gilded.

close up of the gesso halo on St Joseph

Note the pin prick holes in the gesso that shouldn’t be there!

gold leaf on vellum

Applying the first layer of loose gold leaf

lapis lazuli and azurite pigments applied

Layers of azurite and lapiz applied to reach a deep blue within the cave

First wash of Caput Mortuum pigment applied on the earth and shepherd.

Blessed Virgin and Christ child painted in egg tempera on vellum

Close up of the tiny faces of the Blessed Virgin and Christ child

9 finished armenian nativity Cruwys

Completed illumination on vellum of the Armenian Nativity

Colour palette: Caput Mortuum, Azurite, Lapis lazuli dark, vermillion, terre verte, ivory black and titanium white.

All these pigments can be obtained from L. Cornelissen & Son, Great Russell Street, London where this piece is now on display as part of the Heritage Craft Association‘s exhibition with Cornelissen’s celebrating ‘Gold on Parchment’, for the upcoming London Craft Week, where some practical demonstrations will be taking place.

Thanks for reading!

Ronnie
